Figure 1: Premises Diagram Reference Layout
An applicant shall submit to the Department, with the application, a complete and detailed diagram of the proposed premises. The diagram shall be used by the Department to determine whether the premises meets the requirements under this division and the Act. The Department shall deny an application if the premises does not qualify for licensure.
The diagram shall show the boundaries of the property and the proposed premises to be licensed, showing all boundaries, entrances and exits, interior partitions, walls, rooms, windows, and doorways, and shall include a brief statement or description of the principal activity to be conducted therein. The diagram shall also include the dimensions of the boundaries of the premises and structures, including interior and exterior dimensions, to clearly identify the bounds of the premises.
The diagram shall show and identify commercial cannabis activities that will take place in each area of the premises, and identify limited-access areas. Commercial cannabis activities that shall be identified on the diagram include the following, if applicable to the business operations: storage, batch sampling, loading or unloading of shipments, packaging and labeling, customer sales, loading for deliveries, extraction, infusion, cultivation, and processing.
The diagram shall show where all cameras are located and assign a number to each camera for identification purposes unless the premises is exempt from the video surveillance requirement.
The diagram shall be to scale to clearly determine the bounds of the premises.
If the proposed premises consists of only a portion of a property, the diagram must be labeled indicating which part of the property is the proposed premises and for what purpose(s) the remaining property is used.
If the proposed premises consists of only a portion of a property that will contain two or more licensed premises, the diagram shall clearly show the designated entrances and walls under the exclusive control of the commercial cannabis business for the premises, as well as the designated entrances and walls for each additional premises. The diagram shall also show all proposed common or shared areas of the property. Such areas may include lobbies, bathrooms, hallways, and breakrooms.
If the commercial cannabis business is seeking a license to conduct cultivation activities on the proposed premises, the following must be clearly identified on the premises diagram:
All roads and water crossings on the property.
All water sources identified and labeled for beneficial use type, including but not limited to, irrigation, domestic, fire protection, power, fish and wildlife preservation and enhancement, and recreation.
If the commercial cannabis business is proposing to use a diversion from a waterbody or an underground stream flowing in a known and definite channel, groundwater well, or rain catchment system as a water source for cultivation.
